DAT-4S Surveillance UAV

DAT-4 is used as an aircraft platform to make surveillance UAV which is labeled as DAT-4S.

Within communication range, live video can be transferred to Ground Control Station and RVT (Real-time Video Terminal). Telemetry and remote control in real-time can be achieved through wireless data link (Micro Wave or Satellite, optionally).

Description



Features:

  • Work normally in severe weather: cold, hot, snow, and rain.
  • Work normally in harsh electromagnetic environment.
  • 20kg payload @ 6 hours endurance.
  • Maximum range: 700km.
  • Live video transferring range: 100km @6h endurance (150km range optional).
  • Locking and tracking moving target on the ground (option).
  • Telemetry and tele-control range: not less than 120km. bigger range available on demand.
  • World leading level: Extremely Short time delay of video and data transmission, minimum 35ms, this feature is necessary for target locking and tracking.
  • Taking video in both day and night: HD Video and infrared image.
  • Taxiing Take-off on a short runway or beach and Taxiing Landing.
  • Recovered by parachute in emergency (optional).
  • Various usages: widely used in field of geophysical prospecting, power grid patrol, oil
    pipeline surveillance, transportation, border patrol.
Specifications of DAT-4S:
Dimensions Length 3.4m
Wingspan 4.62m
Height 1.12m
Size of Payload Cabin 920*340*350mm
Power Engine Gasoline engine
Platform DAT-4
Sensor One gimbal
Video Visible light video HD video, resolution: 1920X1080p, 30X
Infrared video(thermal  image) 640X480
Performance Cruising Speed 120km/hour
  Max Range of flying 700km (435mile)
Max Range of live  video transmission 100km (bigger range optional)
Max Range of telemetry and remote  control 120km+ (bigger range optional)
Ceiling 3,000m(10,000ft)
Max Endurance 6 hours
Takeoff/Landing Taxiing takeoff, taxiing landing, parachute landing
Control Mode Autonomous control + remote control; Airline pre-store or uploading in real time
Navigation GPS/ BDS navigation
Maintenance Engine maintenance cycle time ≥ 150h
Environment Temperature Operating temperature: -20℃~50℃
Wind Load Rating 6 grade (10.8~13.9 m/s)



*** หากท่านใดสนใจ สามารถติดต่อได้ที่ Line ID : @droneacademy ***
